Standard UV Lamps--UV lamp factory

Product Advantages：

1. The inner wall of the lamp tube is coated with a long-life coating, which can effectively reduce the UV light attenuation during the life span of the lamp;

2. Use quartz glass tubes with high penetration of 253.7nm and 185nm wavelengths, which can effectively increase the UV output intensity;

3. Use electronic powder with unique formula to effectively improve the ion bombardment resistance of the lamp electrode and extend the lamp life span;

4. Lamps can be designed and customized according to customer requirements;

Dimension Diagram：

Product Specifications：

NO.	Model	Diameter [OD]（mm）	Mounted length [A]（mm）	Lamp power(W)	Lamp current(A)	Lamp voltage(V)	UVC radiation intensity（uw/cm²）	UVC radiant power（W）	Using lifetime（h）	UVCmaintenance rate（%）
1	GPH136T5L/4-4W	15	136	4	0.17	29	9	0.9	12000	≥85
2	GPH212T5L/4-6W	15	212	6	0.16	42	15	1.5	12000	≥85
3	GPH283T5L/4-8W	15	283	8	0.15	56	20	2.1	12000	≥85
4	GPH212T5L/4-10W	15	212	10	0.425	25	25	2.7	12000	≥85
5	GPH287T5L/4-14W	15	287	14	0.425	34	40	4	12000	≥85
6	GPH303T5L/4-15W	15	303	15	0.425	35	40	4.3	12000	≥85
7	GPH357T5L/4-17W	15	357	17	0.425	42	55	5.7	12000	≥85
8	GPH436T5L/4-21W	15	436	21	0.425	51	70	7.3	12000	≥85
9	GPH793T5L/4-38W	15	793	38	0.425	92	125	13.5	12000	≥85
10	GPH843T5L/4-40W	15	843	40	0.425	98	145	16	12000	≥85
11	GPH1148T5L/4-55W	15	1148	55	0.425	135	185	22	12000	≥85
12	GPH1554T5L/4-75W	15	1554	75	0.425	179	250	33	12000	≥85
13	GPH1630T5L/4-79W	15	1630	79	0.425	189	260	34.5	12000	≥85
