Amalgam UV Lamps--UV lamp factory

Product Advantages：

1. The inner wall of the lamp tube is coated with a long-life coating, which can effectively reduce the UV light attenuation during the life span of the lamp;

2. Use quartz glass tubes with high penetration of 253.7nm and 185nm wavelengths, which can effectively increase the UV output intensity;

3. Use electronic powder with unique formula to effectively improve the ion bombardment resistance of the lamp electrode and extend the lamp life span;

4. Use amalgam to control mercury vapor pressure, which effectively solve the UVC output drop problem caused by the rise of lamp tube wall temperature;

5. Applicated in water treatment equipment, with water temperature fluctuating 5~40°C, and the UVC output fluctuating less than 10%;

6. Lamps can be designed and customized according to customer requirements;

Dimension Diagram：

Product Specifications：

NO.	Model	Diameter [OD]（mm）	Mounted length [A]（mm）	Lamp power(W)	Lamp current(A)	Lamp voltage(V)	UVC radiation intensity（uw/cm²）	UVC radiant power（W）	Using lifetime（h）	UVCmaintenance rate（%）
1	GPHHA357T5L/4-42W	15	357	42	1.2	36	110	11	12000	≥85
2	GPHHA357T6L/4-55W	19	357	57	1.8	32	130	13	12000	≥85
3	GPHHA357T6L/4-65W	19	357	65	2.1	31	140	14	12000	≥85
4	GPHHA843T5L/4-105W	15	843	105	1.2	88	325	35	12000	≥85
5	GPHHA1000T5L/4-127W	15	1000	127	1.2	107	375	42	12000	≥85
6	GPHHA843T6L/4-127W	19	843	127	1.8	71	395	43	12000	≥85
7	GPHHA1000T6L/4-150W	19	1000	150	1.8	84	460	52	12000	≥85
8	GPHHA843T6L/4-172W	19	843	172	2.1	82	500	54	12000	≥85
9	GPHHA1554T5L/4-190W	15	1554	190	1.2	164	520	68	12000	≥85
10	GPHHA1000T6L/4-207W	19	1000	207	2.1	99	580	65	12000	≥85
11	GPHHA1148T6L/4-205W	19	1148	205	2.1	98	600	70	12000	≥85
12	GPHHA1554T6L/4-240W	19	1554	240	1.8	134	680	89	12000	≥85
13	GPHHA1554T6L/4-320W	19	1554	300	2.1	154	800	105	12000	≥85
14	GPHHA1554T9L/4-400W	28	1554	400	3.8	105	1100	144	12000	≥85
15	GPHHA1575T10L/4-500W	32	1575	500	5.5	92	1210	158	12000	≥85
16	GPHHA1575T12L/4-750W	38	1575	745	8	96	1615	210	12000	≥85

Foshan YaoQing UV technology Co., Ltd.
